Bay Laurel
Bay Laurel
Mechotech designs and manufactures turnkey spices oils distillation plants for Bay Laurel (Laurus nobilis). We supply the complete machinery to process Bay Laurel into an essential oil configured to the client’s target specification for the pharmaceutical, nutraceutical, food, and fragrance industries. Bay laurel (Laurus nobilis) oil is steam-distilled from the leaves and is rich in 1,8-cineole (typically 30–55%), α-terpinyl acetate and linalool, with food flavouring, fragrance and hair-care uses.
Mechotech's Bay Laurel plant is configured around the specific chemistry and processing requirements of Bay Laurel. Built in SS 316L with integrated condensers and oil-water separation, PLC-based automation, and full documentation, each plant is delivered as a commissioned turnkey system. Bay laurel leaves are dry, leathery leaves, so the line is built around cleaning and cutting or crushing the leaves and a still sized for a bulky leaf charge; 1,8-cineole is the listed marker compound.
Technical Specifications
| Product | Bay Laurel Distillation Plant |
|---|---|
| Process Category | Spices Oils Distillation Plants |
| Plant Part | Leaves |
| Botanical Name | Laurus nobilis |
| Marker Compound | 1,8-Cineole (per the Sureka Life Sciences catalogue entry for Bay Laurel Distillation, spice oil category) |
| Principal Documented Constituent | 1,8-cineole |
| Extract Type | Essential oil, with aromatic hydrosol as a recoverable co-product |
| Extraction Method | Steam, hydro (hydrodistillation), vacuum or pressure distillation — selected for the volatility and heat-sensitivity of the target oil |
| Product-contact Material | SS 316L, CIP-capable |
| Condensation & Separation | Multi-tube condenser with chilled-water circulation; stainless-steel Florentine flask for oil–water separation |
| Polishing | Polish filtration; drying over anhydrous sodium sulphate or by vacuum |
| Quality Control | GC-MS and physical parameters (specific gravity, refractive index, optical rotation) verified per batch |
| Utility Requirements | Steam, chilled/cooling water, compressed air, soft water, power (project-specific) |
| Automation | PLC-based automation |
| Plant Capacity | Configured to requirement |
| Final Product Form | Essential oil (liquid) and recoverable hydrosol |
Plant Capacities
| Plant Scale | Raw Material Throughput | Typical Use |
|---|---|---|
| Pilot | Configured to your feedstock and trial plan | Product development, parameter validation |
| Semi-Commercial | Configured between pilot and commercial scale | Contract manufacturing, scale-up trials |
| Commercial | Configured to raw-material supply and confirmed buyer volume | Commercial production at confirmed buyer volume |
Capacity is configured to raw-material supply and confirmed buyer volume; we recommend a pilot plant to validate process parameters before scaling.
Manufacturing Process
Raw Material Preparation
Bay laurel (Laurus nobilis) leaves are cleaned and cut or crushed so that steam reaches the oil-bearing tissue; the cut size and charge density are set during process development.
Charging & Distillation
The prepared Bay Laurel charge is loaded into the SS 316L still and distilled by steam, hydro (hydrodistillation), vacuum, or pressure distillation — selected for the volatility and heat-sensitivity of the target oil.
Condensation
Vapours pass through an efficient multi-tube condenser with chilled-water circulation, condensing the volatile oil and hydrosol.
Oil–Water Separation
Condensate is separated in a stainless-steel Florentine flask; the essential oil is collected while the hydrosol is drawn off (and can be recovered as a co-product).
Polishing & Drying
The crude oil is polish-filtered and dried over anhydrous sodium sulphate (or by vacuum) to remove residual moisture.
Quality Control
Each batch of Bay Laurel oil is verified by GC-MS and physical parameters (specific gravity, refractive index, optical rotation) before release.
Major Plant Equipment
- Raw material cleaning and sorting (with size reduction where required)
- SS 316L distillation still
- Steam distribution system
- Multi-tube condenser (chilled-water circulation)
- Stainless-steel Florentine oil–water separator
- Polish filtration and drying unit (anhydrous sodium sulphate or vacuum)
- Hydrosol collection
- Essential oil and hydrosol storage tanks
- CIP (clean-in-place) system
- PLC-based automation panel
Plant Output
From Plant to Product
Bay Laurel Distillation
This botanical is also in the product range of Sureka Life Sciences, our sister concern in botanical ingredients.
Applications
- Food flavouring
- Fragrance
- Hair-care products
- Cosmetics and pharmaceuticals
- Industrial uses (as listed by Sureka Life Sciences)
Key Features
SS 316L Construction
All product-contact surfaces are SS 316L for corrosion resistance and product purity, with CIP capability between batches.
Efficient Condensation
High-surface-area multi-tube condensers with chilled-water circulation maximise oil recovery and minimise losses of volatile top-notes.
Leaf-Charge Distillation
The still is configured for a bulky bay leaf charge, with the distillation mode set during process development.
Hydrosol Recovery
Integrated separation allows recovery of the aromatic hydrosol as a co-product.
Scalable Capacity
Plants are configured to requirement from pilot scale upward, with modular expansion.
