Mechotech designs and manufactures turnkey spices oils distillation plants for Cinnamon Bark. Cinnamon bark oil is dominated by cinnamaldehyde (typically 65–80%), the premium-priced, sweet-spicy marker compound used in fine flavour, fragrance, and food applications. We supply the complete machinery to process Cinnamon bark into an essential oil configured to the client’s target specification for the pharmaceutical, nutraceutical, food, and fragrance industries.
Mechotech's Cinnamon plant is configured around the specific chemistry and processing requirements of Cinnamon bark oil. Because cinnamaldehyde-rich bark oil is denser than water — settling below the hydrosol, unlike most essential oils — the Florentine flask separation stage is configured accordingly. Built in SS 316L with integrated condensers and oil-water separation, automation, and full documentation, each plant is delivered as a commissioned turnkey system. Cinnamon bark is a dense, rolled bark, so the line is built around size reduction so that steam reaches the oil-bearing tissue; cinnamaldehyde is the marker for the bark oil, whereas the leaf oil is eugenol-dominant and sits on a separate page.
Technical Specifications
| Product | Cinnamon Distillation Plant |
|---|---|
| Botanical Name | Cinnamomum zeylanicum / cassia (per catalogue) |
| Raw Material | Cinnamon |
| Plant Part | Bark |
| Product Category | Spices Oils Distillation Plants |
| Extraction Method | Steam, hydro, vacuum or pressure distillation — selected for the volatility and heat-sensitivity of the target oil |
| Product-contact Material | SS 316L |
| Condensation | Multi-tube condenser with chilled-water circulation |
| Oil–Water Separation | Stainless-steel Florentine flask |
| Finishing | Polish filtration; drying over anhydrous sodium sulphate or by vacuum |
| Automation | PLC-based |
| Plant Capacity | Configured to requirement |
| Final Product Form | Cinnamon essential oil; aromatic hydrosol as co-product |
Plant Capacities
| Plant Scale | Raw Material Throughput | Typical Use |
|---|---|---|
| Pilot | Configured to your feedstock and trial plan | Product development, parameter validation |
| Semi-Commercial | Configured between pilot and commercial scale | Scale-up trials, contract manufacturing |
| Commercial | Configured to raw-material supply and confirmed buyer volume | Commercial production |
Capacity is configured to raw-material supply, confirmed buyer volume and investment timeline; a pilot plant is recommended to validate parameters before scaling.
Manufacturing Process
Raw Material Preparation
Cinnamon bark is cleaned and ground or crushed to rupture the oil-bearing cells and open channels for steam, since intact bark distils slowly and incompletely (per Mechotech’s cinnamon distillation article); the particle size is set during process development.
Charging & Distillation
The prepared Cinnamon charge is loaded into the SS 316L still and distilled by steam, hydro, vacuum, or pressure distillation — selected for the volatility and heat-sensitivity of the target oil.
Condensation
Vapours pass through an efficient multi-tube condenser with chilled-water circulation, condensing the volatile oil and hydrosol.
Oil–Water Separation
Condensate is separated in a stainless-steel Florentine flask; the essential oil is collected while the hydrosol is drawn off (and can be recovered as a co-product).
Polishing & Drying
The crude oil is polish-filtered and dried over anhydrous sodium sulphate (or by vacuum) to remove residual moisture.
Quality Control
Each batch of Cinnamon oil is verified by GC-MS and physical parameters (specific gravity, refractive index, optical rotation) before release.
Major Plant Equipment
- Raw material cleaning and sorting system
- Size-reduction unit (where required)
- SS 316L distillation still / extractor
- Multi-tube condenser with chilled-water circulation
- Stainless-steel Florentine flask (oil–water separator)
- Polish filtration system
- Drying unit (anhydrous sodium sulphate or vacuum)
- CIP system
- PLC-based automation and instrumentation
Plant Output
Case Study
Cinnamon Essential Oil Distillation Plant
See how this plant was engineered and delivered for a real project.
Applications
- Pharmaceutical standardised ingredient supply
- Nutraceutical capsule, tablet, and supplement manufacturing
- Food, flavour, and beverage applications
- Cosmetic and personal care active ingredients
- Ayurvedic and traditional medicine preparations
- Export to regulated-market ingredient buyers
Key Features
SS 316L Construction
All product-contact surfaces are SS 316L for corrosion resistance and product purity, with CIP capability between batches.
Efficient Condensation
High-surface-area multi-tube condensers with chilled-water circulation condense the volatile oil and hydrosol.
Steam / Hydro / Vacuum / Pressure
The still is configured for the distillation mode best suited to the feedstock, protecting heat-sensitive aroma compounds.
Hydrosol Recovery
Integrated separation allows the aromatic hydrosol to be recovered as a co-product.
Scalable Capacity
Plants are configured to requirement from pilot scale upward, with modular expansion.
